ModelGP2501-TC11→TypeTFT color LCDDisplay Colors256 colors (no blink)/ 64 colors (3-speed blink)(software control).1BacklightCCFL (Service life: 50,000 hrs. Operation)Resolution640 × 480 pixelsEffective Display Area (mm)211.2(W) × 158.4(H)Brightness Control4 levels of adjustment available via touch panelContrast Control-Language Character SetsASCII: (Code page 850) Alphanumeric (incl. European characters)Chinese: (GB2312-80 codes) simplified Chinese fontsJapanese: ANK 158, Kanji: 6962 (JIS Standards 1 & 2)Korean: (KSC5601 - 1992 codes) Hangul fontsTaiwanese: (Big 5 codes) traditional Chinese fontsText8 × 8 dots80 char.
× 60 rows8 × 16 dots80 char. × 30 rows16 × 16 dots40 char. Changing the 'Colors' setting to '256 colors' will disable the blink feature on all your project screens. If you wish to use the blink feature, do not change this setting to '256 colors.'
Gp2600 Proface Manual Free
. The display font will differ depending on which (language) character, or which size you select. Only available when using '1/2 Byte Character' settings via software. (Only Japanese, Chinese, Taiwanese and Korean characters.). A Lithium battery's lifetime is:10 years when the battery's ambient temperature is under 40℃4.1 years when the battery's ambient temperature is under 50℃1.5 years when the battery's ambient temperature is under 60℃When used for backup:Approximately 60 days, with a fully charged batteryApproximately 6 days, with a half-charged battery. SIEMENS SIMATIC S7-200/300/400 series (MPI port only).
Please contact your Pro-face sales representative for supported models and other details. Using the AUX Input/Output I/F requires the separately sold Screw Lock Terminal Block (GPL-AXCN01). Windows drivers cannot be used. However, certain types of printers with both Windows and DOS drivers can be used. For details, contact your local Pro-face distributor. When installing the GP in a cabinet or enclosure, the term “ambient operation temperature” indicates the cabinet or enclosure’s internal temperature. Big l return of the devil s son zip. The LCD displays may occasionally blur when they are used for hours at over 40℃ ambient operating temperature.
This is a temporary phenomenon. After the temperature returns to normal, the display will be restored to normal. The GP's operation will not be affected even though the display is blurred. The degree of protection provided by these products is equivalent to IP65f, however their performance cannot be guaranteed for every environment. Be sure to confirm your work environment requirements prior to installation.
Gp2600 Proface Manuals
The Pro-Face / Xycom GP-2400/2500/2600 Series Programmable Operator Interface is equipped with a variety of new and useful items, such as an Ethernet, CF Card, Sound and Expansion Serial interfaces as standard equipment. The following explanation describes these.The GP-2400/2500/2600 series unit comes with an Ethernet 10BASE-T connector as standard equipment. In addition to sending screen data to the GP, this feature can also be used to set up the GP, even if the unit is used for the first time.This interface allows use of the CF Card instead of the optional Memory Loader II to store GP setup.
and screen data, and then transfer it to the GP. Also, it allows read and write data to existing (optional) Multi-Unit's CF Card, since the GP-2400/2500/2600's card is the same type. The CF Card can also be used for the storage and transfer of recipe, logging, alarm history and bmp data files. The GP can read these files from the CF Card, or use the CF Card to store data read out from the host (PLC).With the GP-2400/2500/2600, connection can be made to a speaker to the GP's sound output Terminal to enable sound output, without connecting the optional Multi Unit.The expansion serial interface allows connection to a variety of equipment, including a bar-coder reader, a serial code reader or an I/O device.Setting up the GP means downloading the required system and protocol programs from the GP screen creation software to the GP. Buying used equipment doesn't always have to be a shot in the dark.
